API Reference

Base URL

https://api.smole.tech

Authentication

Include your API key in the X-API-Key header:

X-API-Key: ak_your_api_key

Schema Endpoints

Manage your extraction schemas. See Schemas for examples of creating and using schemas.

Workflow Endpoints

A workflow is a reusable way to process documents: it references one schema and adds its own preparation settings. Workflows belong to a workspace; get your workspace ID from GET /v1/workspaces. Paths below start with /v1/workspaces/:workspaceId.

Workflow body

POST sends this object; PUT sends it as input. Every key is required and unknown keys are rejected. schemaId is a built-in schema or one of yours, and maxPages is null or 1 to 10,000.

{
  "title": "Invoices (scans)",
  "description": "Scanned supplier invoices",
  "schemaId": "123e4567-e89b-12d3-a456-426614174000",
  "definition": {
    "contractVersion": 2,
    "preparation": {
      "forceOcr": true,
      "preserveTables": true,
      "preserveLinks": true,
      "maxPages": null
    }
  }
}

Saving is publishing. A save that changes the schema or the preparation settings creates the next version (latestVersion, latestVersionId); a new title or description does not. Each save, and archiving an active workflow, increases revision, so send the revision you last read as expectedRevision. Versions are immutable, and a run keeps the version it started with, even if the workflow is edited or archived while it runs.

Webhook Endpoints

Webhooks send a signed event to your endpoint each time a run of a workflow finishes. See Webhooks for events, signatures and retries. Paths below start with /v1/workspaces/:workspaceId.

Pipeline Endpoints

Process documents through the extraction pipeline. See Configuration for all available parameters.

Documents and billing

Each submitted file is one document, whatever its page count, and uses 1 document unit of your plan. Conversion, OCR and extraction in one pipeline count together. Usage is reserved while a job runs, counted once when it succeeds and released if it fails or is cancelled. After a client timeout, check the existing job before submitting again to avoid duplicate work.

processingMode is optional and accepted for compatibility: both values, normal and fast, are processed the same way at the same price. processingQuoteId is optional and no longer needed. GET /api/users/me/usage reports document counts, allowance usage and pending reservations.

Run a workflow

Send exactly one of schemaId or workflowId. A workflow run uses the workflow's latest version, and that version supplies the schema and the preparation settings. The Idempotency-Key header works as for any run.

curl -X POST https://api.smole.tech/api/pipeline/file \
  -H "X-API-Key: ak_your_api_key" \
  -F "file=@invoice.pdf" \
  -F "workflowId=your_workflow_id"

# The workflow's runs, newest first
curl "https://api.smole.tech/api/pipeline?workflowId=your_workflow_id" \
  -H "X-API-Key: ak_your_api_key"

Processing options cannot be sent with workflowId: the file route rejects quality, extractImages, preserveLinks, preserveTables, maxPages, ocrEnabled, ocrForce and ocrLanguages, and the URL and base64 routes reject conversionOptions and extractionChunking, each with 400 PIPELINE_VALIDATION_ERROR. The list filter returns an empty list for an unknown workflow and cannot be combined with ids.

A workflow run is a normal pipeline job and is billed like one: it uses 1 document unit, and failed runs, including RESULT_SCHEMA_INVALID, and cancelled runs are not charged: their reservation is released. Creating, editing, viewing and exporting workflows is free.

API Key Scopes

Workflow and webhook routes need a file key created for the workspace in Account → API keys, with the scopes the request needs. Processing keys work on the /api routes only.

User Endpoints

Response Format

Pipeline job response:

{
  "id": "550e8400-e29b-41d4-a716-446655440000",
  "status": "completed",
  "processingMode": "normal",
  "schemaId": "123e4567-e89b-12d3-a456-426614174000",
  "schemaVersion": 3,
  "workflowId": "9b2f6a1e-4c1d-4f7a-9e3b-2d5c8a7f1e04",
  "workflowVersionId": "0c8e4d2a-7b5f-4e19-8a63-1f9d2c4b6e57",
  "workflowVersion": 2,
  "steps": [
    { "name": "conversion", "status": "completed" },
    { "name": "extraction", "status": "completed" }
  ],
  "result": {
    "invoiceNumber": "INV-12345",
    "total": 150.00,
    "date": "2024-01-15",
    "purchaseOrder": null
  },
  "totalCostCents": 5,
  "createdAt": "2024-01-15T10:00:00Z",
  "completedAt": "2024-01-15T10:00:15Z"
}

Fields that couldn't be found in the document are returned as null. See Missing Data and Null Values for details.

schemaVersion is the schema version the run used. workflowId, workflowVersionId and workflowVersion identify the workflow version a run pinned, and are null for runs with a schemaId. Items of GET /api/pipeline carry these fields too. A failed run, from GET /api/pipeline/:id or the list, also has error, errorCode, errorStage (conversion or extraction) and errorRetryable.

Error Codes

Errors from the /api route handlers use the first body below, sometimes with details. An unknown, disabled or expired API key, or a missing sign-in, returns 401 with only { message }. The /v1 workflow routes, and permission errors on every route, /api included, use the second body, as does 401 INVALID_API_KEY for a key that is not bound to the workspace:

{ "error": "WORKFLOW_ARCHIVED", "message": "This workflow is archived and cannot run" }

{
  "code": "WORKFLOW_REVISION_CONFLICT",
  "message": "This workflow changed. Reload it before saving.",
  "retryAction": "change_input",
  "requestId": "…"
}

A key without the scope a route needs gets 403 PERMISSION_DENIED in the second body.
